Inputs & Outputs
|
- One Analog Input (6-60V DC) on Supply Voltage
|
|
|
Power
|
- Input voltage range: 6-60V DC
- High Efficiency DC-DC converter
- Low Power Consumption of < 2 Watts
|
|
| |
|
Communication
|
- RS-485 Modbus RTU port for communication with up to 8 Slaves
- Modbus TCP Client mode for communication with up to 8 Servers
- Modbus TCP Server mode to interface with SCADA systems
|
|
|
Network
|
- 100 Mbit Ethernet
- 3G and 4G LTE (via external USB Stick)
|
|
|
Storage
|
- 512 KB RAM
- 16 GB MicroSD Card
|
|
|
Data Collection & Export
|
- CSV format
- HTTP / HTTPS / FTP / SFTP / MQTT / MQTTS
|
|
|
Characteristics
|
|
Enclosure Material
|
Polyamide, UL 94 V0
|
|
Enclosure Colour
|
Light Grey, similar to RAL 7035
|
|
Degree of Protection
|
IP20 (Finger Protected)
|
|
Operating Temperature
|
0-60 °C
|
|
DIN Standard Mount
|
DIN EN 60529
|
|
Dimensions (L x W x H)
|
105 x 23 x 115 mm
|
|
Weight
|
160 g
|
|
|
